Overview

Dataplex Universal Catalog is an intelligent data fabric that enables organizations to centrally discover, manage, monitor, and govern their data across data lakes, data warehouses, and data marts to power analytics at scale.

Data Catalog is a fully managed, scalable metadata management service within Dataplex Universal Catalog. It offers a simple and easy-to-use search interface for data discovery, a flexible and powerful cataloging system for capturing both technical and business metadata, and a strong security and compliance foundation with Cloud Data Loss Prevention (part of Sensitive Data Protection) and Identity and Access Management (IAM) integrations.

Using Data Catalog

Using Data Catalog within Dataplex Universal Catalog, you can search for assets to which you have access, and you can tag data assets to support discovery and access control. Tags allow you to attach custom metadata fields to specific data assets for easy identification and retrieval (such as tagging certain assets as containing protected or sensitive data); you can also create reusable tag templates to rapidly assign the same tags to different data assets.

What you'll learn

In this lab, you learn how to:

• Enable the Data Catalog API.

• Configure Dataplex Universal Catalog connectors for PostgreSQL and MySQL.

• Search for PostgreSQL and MySQL entries in Data Catalog within Dataplex Universal Catalog.

Prerequisites

Note: Before starting this lab, log out of your personal or corporate gmail account, or run this lab in Incognito. This prevents sign-in confusion while the lab is running.

Setup and requirements

Before you click the Start Lab button

Read these instructions. Labs are timed and you cannot pause them. The timer, which starts when you click Start Lab, shows how long Google Cloud resources are made available to you.

This hands-on lab lets you do the lab activities in a real cloud environment, not in a simulation or demo environment. It does so by giving you new, temporary credentials you use to sign in and access Google Cloud for the duration of the lab.

To complete this lab, you need:

• Access to a standard internet browser (Chrome browser recommended).

Note: Use an Incognito (recommended) or private browser window to run this lab. This prevents conflicts between your personal account and the student account, which may cause extra charges incurred to your personal account.

• Time to complete the lab—remember, once you start, you cannot pause a lab.

Note: Use only the student account for this lab. If you use a different Google Cloud account, you may incur charges to that account.

How to start your lab and sign in to the Google Cloud console

1. Click the Start Lab button. If you need to pay for the lab, a dialog opens for you to select your payment method. On the left is the Lab Details pane with the following:

   • The Open Google Cloud console button

   • Time remaining

   • The temporary credentials that you must use for this lab

   • Other information, if needed, to step through this lab

2. Click Open Google Cloud console (or right-click and select Open Link in Incognito Window if you are running the Chrome browser).

   The lab spins up resources, and then opens another tab that shows the Sign in page.

   Tip: Arrange the tabs in separate windows, side-by-side.

   Note: If you see the Choose an account dialog, click Use Another Account.

3. If necessary, copy the Username below and paste it into the Sign in dialog.

    student-04-ac7af5164ab1@qwiklabs.net


   Copied!content_copy

   You can also find the Username in the Lab Details pane.

4. Click Next.

5. Copy the Password below and paste it into the Welcome dialog.

    8I32kQjyDTrC


   Copied!content_copy

   You can also find the Password in the Lab Details pane.

6. Click Next.

   Important: You must use the credentials the lab provides you. Do not use your Google Cloud account credentials.

   Note: Using your own Google Cloud account for this lab may incur extra charges.

7. Click through the subsequent pages:

   • Accept the terms and conditions.

   • Do not add recovery options or two-factor authentication (because this is a temporary account).

   • Do not sign up for free trials.

After a few moments, the Google Cloud console opens in this tab.

Note: To access Google Cloud products and services, click the Navigation menu or type the service or product name in the Search field.

Activate Cloud Shell

Cloud Shell is a virtual machine that is loaded with development tools. It offers a persistent 5GB home directory and runs on the Google Cloud. Cloud Shell provides command-line access to your Google Cloud resources.

1. Click Activate Cloud Shell at the top of the Google Cloud console.

2. Click through the following windows:

   • Continue through the Cloud Shell information window.

   • Authorize Cloud Shell to use your credentials to make Google Cloud API calls.

When you are connected, you are already authenticated, and the project is set to your Project_ID, qwiklabs-gcp-01-e95a618039b3. The output contains a line that declares the Project_ID for this session:

Your Cloud Platform project in this session is set to qwiklabs-gcp-01-e95a618039b3

gcloud is the command-line tool for Google Cloud. It comes pre-installed on Cloud Shell and supports tab-completion.

3. (Optional) You can list the active account name with this command:

gcloud auth list

Copied!content_copy

4. Click Authorize.

Output:

ACTIVE: *
ACCOUNT: student-04-ac7af5164ab1@qwiklabs.net

To set the active account, run:
    $ gcloud config set account `ACCOUNT`

5. (Optional) You can list the project ID with this command:

gcloud config list project

Copied!content_copy

Output:

[core]
project = qwiklabs-gcp-01-e95a618039b3

Note: For full documentation of gcloud, in Google Cloud, refer to the gcloud CLI overview guide.

Task 1. Enable the Data Catalog API

1. In the Google Cloud console, click on the Navigation menu () > APIs & Services > Library.

2. In the search bar, enter Data Catalog, and select the Google Cloud Data Catalog API.

3. Click Enable.

Note: If you run into an "Action Failed" error after trying to enable the Data Catalog API, try the following steps: click close, refresh your browser tab, then click Enable again.

Click Check my progress to verify the objective.

Enable the Data Catalog API

Check my progress

Task 2. Connect PostgreSQL to Dataplex Universal Catalog

Create a variable for Project ID

• In Cloud Shell, run the following command to set your Project ID as an environment variable:

export PROJECT_ID=$(gcloud config get-value project)

Copied!content_copy

Create the PostgreSQL Database

1. Run the following command to clone the Github repository:

gsutil cp gs://spls/gsp814/cloudsql-postgresql-tooling.zip .
unzip cloudsql-postgresql-tooling.zip

Copied!content_copy

2. Next, change your current working directory to the cloned repo directory:

cd cloudsql-postgresql-tooling/infrastructure/terraform

Copied!content_copy

3. Run the following commands to change the region and zone from us-central1 and us-central1-a to your default assigned region and zone:

export REGION=us-west1
sed -i "s/us-central1/$REGION/g" variables.tf

Copied!content_copy

export ZONE=us-west1-a
sed -i "s/$REGION-a/$ZONE/g" variables.tf

Copied!content_copy

4. Next, execute the init-db.sh script:

cd ~/cloudsql-postgresql-tooling
bash init-db.sh

Copied!content_copy

This will create your PostgreSQL instance and populate it with a random schema. This can take around 10 to 15 minutes to complete.

Note: If you get an Error: Failed to load "tfplan" as a plan file, re-run the init-db script.

Soon after you should receive the following output:

CREATE TABLE factory_warehouse69945.home17e97c57 ( house57588 DATE, paragraph64180 SMALLINT, ip_address61569 JSONB, date_time44962 REAL, food19478 JSONB, state8925 VARCHAR(25), cpf75444 REAL, date_time96090 SMALLINT, reason7955 CHAR(5), phone_number96292 INT, size97593 DATE, date_time609 CHAR(5), location70431 DATE )
 COMPLETED

Click Check my progress to verify the objective.

Create the PostgreSQL Database

Check my progress

Set up the Service Account

1. Create a Service Account:

gcloud iam service-accounts create postgresql2dc-credentials \
--display-name  "Service Account for PostgreSQL to Data Catalog connector" \
--project $PROJECT_ID

Copied!content_copy

2. Next, create and download the Service Account Key:

gcloud iam service-accounts keys create "postgresql2dc-credentials.json" \
--iam-account "postgresql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com"

Copied!content_copy

3. Next, add Data Catalog admin role to the Service Account:

gcloud projects add-iam-policy-binding $PROJECT_ID \
--member "serviceAccount:postgresql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com" \
--quiet \
--project $PROJECT_ID \
--role "roles/datacatalog.admin"

Copied!content_copy

Click Check my progress to verify the objective.

Create a Service Account for PostgreSQL

Check my progress

Execute PostgreSQL to Dataplex Universal Catalog connector

You can build the PostgreSQL connector yourself by going to this GitHub repository.

To facilitate its usage, this lab uses a docker image.

The variables needed were output by the Terraform config.

1. Change directories into the location of the Terraform scripts:

cd infrastructure/terraform/

Copied!content_copy

2. Grab the environment variables:

public_ip_address=$(terraform output -raw public_ip_address)
username=$(terraform output -raw username)
password=$(terraform output -raw password)
database=$(terraform output -raw db_name)

Copied!content_copy

3. Change back to the root directory for the example code:

cd ~/cloudsql-postgresql-tooling

Copied!content_copy

4. Execute the connector:

docker run --rm --tty -v \
"$PWD":/data mesmacosta/postgresql2datacatalog:stable \
--datacatalog-project-id=$PROJECT_ID \
--datacatalog-location-id=$REGION \
--postgresql-host=$public_ip_address \
--postgresql-user=$username \
--postgresql-pass=$password \
--postgresql-database=$database

Copied!content_copy

Soon after you should receive the following output:

============End postgresql-to-datacatalog============

Click Check my progress to verify the objective.

Execute PostgreSQL to Data Catalog connector

Check my progress

Check the results of the script

1. Navigate to Dataplex Universal Catalog in the Google Cloud console by clicking on the Navigation menu () > View all products > Analytics > Dataplex Universal Catalog.

2. Click on Catalog then Aspect types & Tag Templates.

You should see the following postgresql Tag Templates:

3. Click on Entry groups.

You should see the following postgresql Entry Group:

4. Now click on the postgresql Entry Group. Your console should resemble the following:

This is the real value of an Entry Group — you can see all entries that belong to postgresql using the UI.

5. Click on one of the warehouse entries. Look at the Custom entry details and tags:

This is the real value the connector adds—it allows you to have the metadata searchable in Dataplex Universal Catalog.

Clean up

1. To delete the created resources, run the following command to delete the PostgreSQL metadata:

./cleanup-db.sh

Copied!content_copy

2. Now execute the cleaner container:

docker run --rm --tty -v \
"$PWD":/data mesmacosta/postgresql-datacatalog-cleaner:stable \
--datacatalog-project-ids=$PROJECT_ID \
--rdbms-type=postgresql \
--table-container-type=schema

Copied!content_copy

3. Finally, delete the PostgreSQL database:

./delete-db.sh

Copied!content_copy

4. From the Dataplex Universal Catalog menu, under Discover, click on the Search page.

5. In the search bar, enter PostgreSQL and click Search.

You no longer see the PostgreSQL Tag Templates in the results:

Ensure you see the following output in Cloud Shell before you move on:

  Cloud SQL Instance deleted
  COMPLETED

Next, you learn how to do the same thing with a MySQL instance.

Task 3. Connect MySQL to Dataplex Universal Catalog

Create the MySQL database

1. Run the following command in Cloud Shell to return to your home directory:

cd

Copied!content_copy

2. Run the following command to download the scripts to create and populate your MySQL instance:

gsutil cp gs://spls/gsp814/cloudsql-mysql-tooling.zip .
unzip cloudsql-mysql-tooling.zip

Copied!content_copy

3. Now change your current working directory to the cloned repo directory:

cd cloudsql-mysql-tooling/infrastructure/terraform

Copied!content_copy

4. Run the following commands to change the region and zone from us-central1 and us-central1-a to your default assigned region and zone:

export REGION=us-west1
sed -i "s/us-central1/$REGION/g" variables.tf

Copied!content_copy

export ZONE=us-west1-a
sed -i "s/$REGION-a/$ZONE/g" variables.tf

Copied!content_copy

5. Next execute the init-db.sh script:

cd ~/cloudsql-mysql-tooling
bash init-db.sh

Copied!content_copy

This creates your MySQL instance and populate it with a random schema. After a few minutes, you should receive the following output:

CREATE TABLE factory_warehouse14342.persons88a5ebc4 ( address9634 TEXT, cpf12934 FLOAT, food88799 BOOL, food4761 LONGTEXT, credit_card44049 FLOAT, city8417 TINYINT, name76076 DATETIME, address19458 TIME, reason49953 DATETIME )
 COMPLETED

Note: If you get an Error: Failed to load "tfplan" as a plan file, re-run the init-db script.

Click Check my progress to verify the objective.

Create the MySQL Database

Check my progress

Set up the Service Account

1. Run the following to create a Service Account:

gcloud iam service-accounts create mysql2dc-credentials \
--display-name  "Service Account for MySQL to Data Catalog connector" \
--project $PROJECT_ID

Copied!content_copy

2. Next, create and download the Service Account Key:

gcloud iam service-accounts keys create "mysql2dc-credentials.json" \
--iam-account "mysql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com"

Copied!content_copy

3. Next add Data Catalog admin role to the Service Account:

gcloud projects add-iam-policy-binding $PROJECT_ID \
--member "serviceAccount:mysql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com" \
--quiet \
--project $PROJECT_ID \
--role "roles/datacatalog.admin"

Copied!content_copy

Click Check my progress to verify the objective.

Create a Service Account for MySQL

Check my progress

Execute MySQL to Dataplex Universal Catalog connector

You can build the MySQL connector yourself by going to this GitHub repository.

To facilitate its usage, this lab uses a docker image.

The variables needed were output by the Terraform config.

1. Change directories into the location of the Terraform scripts:

cd infrastructure/terraform/

Copied!content_copy

2. Grab the environment variables:

public_ip_address=$(terraform output -raw public_ip_address)
username=$(terraform output -raw username)
password=$(terraform output -raw password)
database=$(terraform output -raw db_name)

3. Change back to the root directory for the example code:

cd ~/cloudsql-mysql-tooling

4. Execute the connector:

docker run --rm --tty -v \
"$PWD":/data mesmacosta/mysql2datacatalog:stable \
--datacatalog-project-id=$PROJECT_ID \
--datacatalog-location-id=$REGION \
--mysql-host=$public_ip_address \
--mysql-user=$username \
--mysql-pass=$password \
--mysql-database=$database

Soon after you should receive the following output:

============End mysql-to-datacatalog============

Click Check my progress to verify the objective.

Execute MySQL to Data Catalog connector

Check my progress

Check the results of the script

1. Navigate to Dataplex Universal Catalog in the Google Cloud console by clicking on the Navigation menu () > View all products > Analytics > Dataplex Universal Catalog.

2. Click on Catalog then Aspect types & Tag Templates.

You should see the following mysql Tag Templates:

3. Click on Entry groups.

You should see the following mysql Entry Group:

4. Now click on the mysql Entry Group. Your console should resemble the following:

This is the real value of an Entry Group — you can see all entries that belong to MySQL using the UI.

5. Click on one of the warehouse entries. Look at the Custom entry details and tags.

This is the real value the connector adds — it allows you to have the metadata searchable in Dataplex Universal Catalog.

Clean up

1. To delete the created resources, run the following command to delete the MySQL metadata:

./cleanup-db.sh

2. Now execute the cleaner container:

docker run --rm --tty -v \
"$PWD":/data mesmacosta/mysql-datacatalog-cleaner:stable \
--datacatalog-project-ids=$PROJECT_ID \
--rdbms-type=mysql \
--table-container-type=database

3. Finally, delete the PostgreSQL database:

./delete-db.sh

Ensure you see the following output in Cloud Shell before you move on:

  Cloud SQL Instance deleted
  COMPLETED

4. From the Dataplex Universal Catalog menu, under Discover, click on the Search page.

5. In the search bar, enter MySQL and click Search.

You no longer see the MySQL Tag Templates in the results.

---

Solution of Lab

Quick

Run the following Commands in CloudShell

export REGION=

curl -LO raw.githubusercontent.com/QUICK-GCP-LAB/2-Minutes-Labs-Solutions/main/Build%20and%20Execute%20MySQL%20PostgreSQL%20and%20SQLServer%20to%20Data%20Catalog%20Connectors/gsp814.sh
sudo chmod +x gsp814.sh
./gsp814.sh

---

Manual

BLACK=`tput setaf 0`
RED=`tput setaf 1`
GREEN=`tput setaf 2`
YELLOW=`tput setaf 3`
BLUE=`tput setaf 4`
MAGENTA=`tput setaf 5`
CYAN=`tput setaf 6`
WHITE=`tput setaf 7`

BG_BLACK=`tput setab 0`
BG_RED=`tput setab 1`
BG_GREEN=`tput setab 2`
BG_YELLOW=`tput setab 3`
BG_BLUE=`tput setab 4`
BG_MAGENTA=`tput setab 5`
BG_CYAN=`tput setab 6`
BG_WHITE=`tput setab 7`

BOLD=`tput bold`
RESET=`tput sgr0`
#----------------------------------------------------start--------------------------------------------------#

echo "${YELLOW}${BOLD}Starting${RESET}" "${GREEN}${BOLD}Execution${RESET}"

gcloud services enable datacatalog.googleapis.com

echo "${YELLOW}${BOLD}Task 1. ${RESET}""${WHITE}${BOLD}Enable the Data Catalog API${RESET}" "${GREEN}${BOLD}Completed${RESET}"

export PROJECT_ID=$(gcloud config get-value project)

gsutil cp gs://spls/gsp814/cloudsql-sqlserver-tooling.zip .
unzip cloudsql-sqlserver-tooling.zip

cd cloudsql-sqlserver-tooling/infrastructure/terraform

sed -i "s/us-central1/$REGION/g" variables.tf

cd ~/cloudsql-sqlserver-tooling
bash init-db.sh

gcloud iam service-accounts create sqlserver2dc-credentials \
--display-name  "Service Account for SQL Server to Data Catalog connector" \
--project $PROJECT_ID

gcloud iam service-accounts keys create "sqlserver2dc-credentials.json" \
--iam-account "sqlserver2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com"

gcloud projects add-iam-policy-binding $PROJECT_ID \
--member "serviceAccount:sqlserver2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com" \
--quiet \
--project $PROJECT_ID \
--role "roles/datacatalog.admin"

cd infrastructure/terraform/

public_ip_address=$(terraform output -raw public_ip_address)
username=$(terraform output -raw username)
password=$(terraform output -raw password)
database=$(terraform output -raw db_name)

cd ~/cloudsql-sqlserver-tooling

docker run --rm --tty -v \
"$PWD":/data mesmacosta/sqlserver2datacatalog:stable \
--datacatalog-project-id=$PROJECT_ID \
--datacatalog-location-id=$REGION \
--sqlserver-host=$public_ip_address \
--sqlserver-user=$username \
--sqlserver-pass=$password \
--sqlserver-database=$database

echo "${YELLOW}${BOLD}Task 2. ${RESET}""${WHITE}${BOLD}SQL Server to Dataplex${RESET}" "${GREEN}${BOLD}Completed${RESET}"

cd

gsutil cp gs://spls/gsp814/cloudsql-postgresql-tooling.zip .
unzip cloudsql-postgresql-tooling.zip

cd cloudsql-postgresql-tooling/infrastructure/terraform

sed -i "s/us-central1/$REGION/g" variables.tf

cd ~/cloudsql-postgresql-tooling
bash init-db.sh

gcloud iam service-accounts create postgresql2dc-credentials \
--display-name  "Service Account for PostgreSQL to Data Catalog connector" \
--project $PROJECT_ID

gcloud iam service-accounts keys create "postgresql2dc-credentials.json" \
--iam-account "postgresql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com"

gcloud projects add-iam-policy-binding $PROJECT_ID \
--member "serviceAccount:postgresql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com" \
--quiet \
--project $PROJECT_ID \
--role "roles/datacatalog.admin"

cd infrastructure/terraform/

public_ip_address=$(terraform output -raw public_ip_address)
username=$(terraform output -raw username)
password=$(terraform output -raw password)
database=$(terraform output -raw db_name)

cd ~/cloudsql-postgresql-tooling

docker run --rm --tty -v \
"$PWD":/data mesmacosta/postgresql2datacatalog:stable \
--datacatalog-project-id=$PROJECT_ID \
--datacatalog-location-id=$REGION \
--postgresql-host=$public_ip_address \
--postgresql-user=$username \
--postgresql-pass=$password \
--postgresql-database=$database


echo "${YELLOW}${BOLD}Task 3. ${RESET}""${WHITE}${BOLD}PostgreSQL to Dataplex${RESET}" "${GREEN}${BOLD}Completed${RESET}"

cd

gsutil cp gs://spls/gsp814/cloudsql-mysql-tooling.zip .
unzip cloudsql-mysql-tooling.zip

cd cloudsql-mysql-tooling/infrastructure/terraform

sed -i "s/us-central1/$REGION/g" variables.tf

cd ~/cloudsql-mysql-tooling
bash init-db.sh

gcloud iam service-accounts create mysql2dc-credentials \
--display-name  "Service Account for MySQL to Data Catalog connector" \
--project $PROJECT_ID

gcloud iam service-accounts keys create "mysql2dc-credentials.json" \
--iam-account "mysql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com"

gcloud projects add-iam-policy-binding $PROJECT_ID \
--member "serviceAccount:mysql2dc-credentials@$PROJECT_ID.iam.gserviceaccount.com" \
--quiet \
--project $PROJECT_ID \
--role "roles/datacatalog.admin"

cd infrastructure/terraform/

public_ip_address=$(terraform output -raw public_ip_address)
username=$(terraform output -raw username)
password=$(terraform output -raw password)
database=$(terraform output -raw db_name)

cd ~/cloudsql-mysql-tooling

docker run --rm --tty -v \
"$PWD":/data mesmacosta/mysql2datacatalog:stable \
--datacatalog-project-id=$PROJECT_ID \
--datacatalog-location-id=$REGION \
--mysql-host=$public_ip_address \
--mysql-user=$username \
--mysql-pass=$password \
--mysql-database=$database

echo "${YELLOW}${BOLD}Task 4. ${RESET}""${WHITE}${BOLD}MySQL to Dataplex${RESET}" "${GREEN}${BOLD}Completed${RESET}"

echo "${RED}${BOLD}Congratulations${RESET}" "${WHITE}${BOLD}for${RESET}" "${GREEN}${BOLD}Completing the Lab !!!${RESET}"

#-----------------------------------------------------end----------------------------------------------------------#
