Cloud SQL with Terraform - GSP234

Cloud SQL with Terraform - GSP234

Overview

In this hands-on lab you will learn how to create Cloud SQL instances with Terraform, then set up the Cloud SQL Proxy, testing the connection with a MySQL client.

Objectives

In this lab, you will:

  • Create a Cloud SQL instance

  • Install the Cloud SQL Proxy

  • Test connectivity with MySQL client using Cloud Shell

Setup

Before you click the Start Lab button

Read these instructions. Labs are timed and you cannot pause them. The timer, which starts when you click Start Lab, shows how long Google Cloud resources will be made available to you.

This hands-on lab lets you do the lab activities yourself in a real cloud environment, not in a simulation or demo environment. It does so by giving you new, temporary credentials that you use to sign in and access Google Cloud for the duration of the lab.

To complete this lab, you need:

  • Access to a standard internet browser (Chrome browser recommended).

Note: Use an Incognito or private browser window to run this lab. This prevents any conflicts between your personal account and the Student account, which may cause extra charges incurred to your personal account.

  • Time to complete the lab---remember, once you start, you cannot pause a lab.

Note: If you already have your own personal Google Cloud account or project, do not use it for this lab to avoid extra charges to your account.

How to start your lab and sign in to the Google Cloud console

  1. Click the Start Lab button. If you need to pay for the lab, a pop-up opens for you to select your payment method. On the left is the Lab Details panel with the following:

    • The Open Google Cloud console button

    • Time remaining

    • The temporary credentials that you must use for this lab

    • Other information, if needed, to step through this lab

  2. Click Open Google Cloud console (or right-click and select Open Link in Incognito Window if you are running the Chrome browser).

    The lab spins up resources, and then opens another tab that shows the Sign in page.

    Tip: Arrange the tabs in separate windows, side-by-side.

    Note: If you see the Choose an account dialog, click Use Another Account.

  3. If necessary, copy the Username below and paste it into the Sign in dialog.

     student-04-2af3977d1925@qwiklabs.net


    You can also find the Username in the Lab Details panel.

  4. Click Next.

  5. Copy the Password below and paste it into the Welcome dialog.

     NcORmb676Xs6


    You can also find the Password in the Lab Details panel.

  6. Click Next.

    Important: You must use the credentials the lab provides you. Do not use your Google Cloud account credentials.

    Note: Using your own Google Cloud account for this lab may incur extra charges.

  7. Click through the subsequent pages:

    • Accept the terms and conditions.

    • Do not add recovery options or two-factor authentication (because this is a temporary account).

    • Do not sign up for free trials.

After a few moments, the Google Cloud console opens in this tab.

Note: To view a menu with a list of Google Cloud products and services, click the Navigation menu at the top-left.

Navigation menu icon

Activate Cloud Shell

Cloud Shell is a virtual machine that is loaded with development tools. It offers a persistent 5GB home directory and runs on the Google Cloud. Cloud Shell provides command-line access to your Google Cloud resources.

  1. Click Activate Cloud Shell

    Activate Cloud Shell icon

    at the top of the Google Cloud console.

When you are connected, you are already authenticated, and the project is set to your Project_ID, qwiklabs-gcp-01-fe55781c4b9f. The output contains a line that declares the Project_ID for this session:

Your Cloud Platform project in this session is set to qwiklabs-gcp-01-fe55781c4b9f

gcloud is the command-line tool for Google Cloud. It comes pre-installed on Cloud Shell and supports tab-completion.

  1. (Optional) You can list the active account name with this command:
gcloud auth list
  1. Click Authorize.

Output:

ACTIVE: *
ACCOUNT: student-04-2af3977d1925@qwiklabs.net

To set the active account, run:
    $ gcloud config set account `ACCOUNT`
  1. (Optional) You can list the project ID with this command:
gcloud config list project

Output:

[core]
project = qwiklabs-gcp-01-fe55781c4b9f

Note: For full documentation of gcloud, in Google Cloud, refer to the gcloud CLI overview guide.

Cloud SQL

Cloud SQL is a fully managed database service that makes it easy to set up, maintain, manage, and administer your relational databases on Google Cloud. You can use Cloud SQL with either MySQL or PostgreSQL.

Task 1. Download necessary files

  1. Create a directory and fetch the required Terraform scripts from the Cloud Storage bucket with:
mkdir sql-with-terraform
cd sql-with-terraform
gsutil cp -r gs://spls/gsp234/gsp234.zip .
  1. Unzip the downloaded content:
unzip gsp234.zip

Task 2. Understand the code

  • Take a look at the contents of the main.tf file:
cat main.tf

Example output:

...
resource "google_sql_database_instance" "master" {
  name                 = "example-mysql-${random_id.name.hex}"
  project              = var.project
  region               = var.region
  database_version     = var.database_version
  master_instance_name = var.master_instance_name

  settings {
    tier                        = var.tier
    activation_policy           = var.activation_policy
    authorized_gae_applications = var.authorized_gae_applications
    disk_autoresize             = var.disk_autoresize
    dynamic "backup_configuration" {
      for_each = [var.backup_configuration]
      content {

        binary_log_enabled = lookup(backup_configuration.value, "binary_log_enabled", null)
        enabled            = lookup(backup_configuration.value, "enabled", null)
        start_time         = lookup(backup_configuration.value, "start_time", null)
      }
    }
    dynamic "ip_configuration" {
      for_each = [var.ip_configuration]
      content {

        ipv4_enabled    = lookup(ip_configuration.value, "ipv4_enabled", true)
        private_network = lookup(ip_configuration.value, "private_network", null)
        require_ssl     = lookup(ip_configuration.value, "require_ssl", null)

        dynamic "authorized_networks" {
          for_each = lookup(ip_configuration.value, "authorized_networks", [])
          content {
            expiration_time = lookup(authorized_networks.value, "expiration_time", null)
            name            = lookup(authorized_networks.value, "name", null)
            value           = lookup(authorized_networks.value, "value", null)
          }
        }
      }
    }
...

Next, you will update the variables.tf file to use the project ID and region allocatedß to this lab.

  1. Click on Open Editor in Cloud Shell.

  2. Open variables.tf and modify the project and region variables to the values shown below:

  • project: qwiklabs-gcp-01-fe55781c4b9f

  • region: us-east4

When finished save the changes made.

Task 3. Run Terraform

The terraform init command is used to initialize a working directory containing Terraform configuration files.

This command performs several different initialization steps in order to prepare a working directory for use. This command is always safe to run multiple times, to bring the working directory up to date with changes in the configuration.

  1. Run terraform init:
terraform init

The terraform plan command is an optional but recommended command and is used to create an execution plan. Terraform performs a refresh, unless explicitly disabled, and then determines what actions are necessary to achieve the desired state specified in the configuration files.

This command is a convenient way to check whether the execution plan for a set of changes matches your expectations without making any changes to real resources or to the state. For example, terraform plan might be run before committing a change to version control, to create confidence that it will behave as expected.

  1. Run terraform plan:
terraform plan -out=tfplan

The optional -out argument can be used to save the generated plan to a file for later execution with terraform apply.

The terraform apply command is used to apply the changes required to reach the desired state of the configuration or the pre-determined set of actions generated by a terraform plan execution plan.

  1. Apply the Terraform plan you just created:
terraform apply tfplan

This will take a little while to complete. Once complete you will see an output as below:

Apply complete! Resources: 5 added, 0 changed, 0 destroyed.

The state of your infrastructure has been saved to the path
below. This state is required to modify and destroy your
infrastructure, so keep it safe. To inspect the complete state
use the `terraform show` command.

State path: terraform.tfstate

Outputs:

generated_user_password =
instance_address = 35.232.204.44
instance_address_time_to_retire =
instance_name = example-mysql-6808
self_link = https://www.googleapis.com/sql/v1beta4/projects/[PROJECT_ID]/instances/example-mysql-6808

Test completed task

Click Check my progress to verify your performed task.

Assessment Completed!

Create Cloud SQL instance using Terraform script.

Check my progress

Assessment Completed!

Task 4. Cloud SQL Proxy

What the proxy provides

The Cloud SQL Proxy provides secure access to your Cloud SQL Second Generation instances without having to allowlist IP addresses or configure SSL.

Accessing your Cloud SQL instance using the Cloud SQL Proxy offers these advantages:

  • Secure connections: The proxy automatically encrypts traffic to and from the database using TLS 1.2 with a 128-bit AES cipher; SSL certificates are used to verify client and server identities.

  • Easier connection management: The proxy handles authentication with Cloud SQL, removing the need to provide static IP addresses.

Note: You do not need to use the proxy or configure SSL to connect to Cloud SQL from App Engine standard or the flexible environment. These connections use a "built-in" proxy implementation automatically.

How the Cloud SQL Proxy works

The Cloud SQL Proxy works by having a local client, called the proxy, running in the local environment. Your application communicates with the proxy with the standard protocol used by your database. The proxy uses a secure tunnel to communicate with its companion process running on the server.

The following diagram shows how the proxy connects to Cloud SQL:

Proxy connection diagram, which includes the 3rd party and cloud SQL code within the cloud SQL and client machine.

Task 5. Installing the Cloud SQL Proxy

  1. Download the proxy:
wget https://dl.google.com/cloudsql/cloud_sql_proxy.linux.amd64 -O cloud_sql_proxy
  1. Make the proxy executable:
chmod +x cloud_sql_proxy

You can install the proxy anywhere in your environment. The location of the proxy binaries does not impact where it listens for data from your application.

Proxy startup options

When you start the proxy, you provide it with the following sets of information:

  • What Cloud SQL instances it should establish connections to

  • Where it will listen for data coming from your application to be sent to Cloud SQL

  • Where it will find the credentials it will use to authenticate your application to Cloud SQL

The proxy startup options you provide determine whether it will listen on a TCP port or on a Unix socket. If it is listening on a Unix socket, it creates the socket at the location you choose; usually, the /cloudsql/ directory. For TCP, the proxy listens on localhost by default.

Task 6. Test connection to the database

  1. Start by running the Cloud SQL proxy for the Cloud SQL instance:
export GOOGLE_PROJECT=$(gcloud config get-value project)
MYSQL_DB_NAME=$(terraform output -json | jq -r '.instance_name.value')
MYSQL_CONN_NAME="${GOOGLE_PROJECT}:us-east4:${MYSQL_DB_NAME}"
  1. Run the following command:
./cloud_sql_proxy -instances=${MYSQL_CONN_NAME}=tcp:3306

Now you'll start another Cloud Shell tab by clicking on plus (+) icon. You'll use this shell to connect to the Cloud SQL proxy.

  1. Navigate to sql-with-terraform directory:
cd ~/sql-with-terraform
  1. Get the generated password for MYSQL:
echo MYSQL_PASSWORD=$(terraform output -json | jq -r '.generated_user_password.value')
  1. Test the MySQL connection:
mysql -udefault -p --host 127.0.0.1 default
  1. When prompted, enter the value of MYSQL_PASSWORD, found in the output above, and press Enter.

  2. You should successfully log into the MYSQL command line. Exit from MYSQL by typing Ctrl + D.

If you go back to the first Cloud Shell tab you'll see logs for the connections made to the Cloud SQL Proxy.

Task 7. Test your understanding

Below are multiple-choice questions to reinforce your understanding of this lab's concepts. Answer them to the best of your abilities.

Which command is used to create a Terraform execution plan?

  • terraform plan

  • terraform ini

  • tterraform apply

Submit

The Cloud SQL Proxy provides secure access to your Cloud SQL instances without having to allowlist IP addresses or configure SSL.

  • True

  • False
