Datastream: PostgreSQL Replication to BigQuery - GSP1052

Overview

In today's competitive environment, organizations need to quickly and easily make decisions based on real-time data. Datastream for BigQuery features seamless replication from operational database sources such as AlloyDB, MySQL, PostgreSQL, and Oracle, directly into BigQuery, Google Cloud's serverless data warehouse. With a serverless, auto-scaling architecture, Datastream allows you to easily set up an ELT (Extract, Load, Transform) pipeline for low-latency data replication enabling real-time insights.

In this hands-on lab you'll deploy Cloud SQL for PostgreSQL database and import a sample data set using the gcloud command line. In the UI you will create and start a Datastream stream and replicate data into BigQuery.

Although you can easily copy and paste commands from the lab to the appropriate place, students should type the commands themselves to reinforce their understanding of the core concepts

What you'll do

• Prepare a Cloud SQL for PostgreSQL instance using the Google Cloud Console

• Import data into the Cloud SQL instance

• Create a Datastream connection profile for the PostgreSQL database

• Create a Datastream connection profile for the BigQuery destination

• Create a Datastream stream and start replication

• Validate that the existing data and changes are replicated correctly into BigQuery

Prerequisites

• Familiarity with standard Linux environments

• Familiarity with change data capture (CDC) concepts

Setup and requirements

Before you click the Start Lab button

Read these instructions. Labs are timed and you cannot pause them. The timer, which starts when you click Start Lab, shows how long Google Cloud resources will be made available to you.

This hands-on lab lets you do the lab activities yourself in a real cloud environment, not in a simulation or demo environment. It does so by giving you new, temporary credentials that you use to sign in and access Google Cloud for the duration of the lab.

To complete this lab, you need:

• Access to a standard internet browser (Chrome browser recommended).

Note: Use an Incognito or private browser window to run this lab. This prevents any conflicts between your personal account and the Student account, which may cause extra charges incurred to your personal account.

• Time to complete the lab---remember, once you start, you cannot pause a lab.

Note: If you already have your own personal Google Cloud account or project, do not use it for this lab to avoid extra charges to your account.

How to start your lab and sign in to the Google Cloud console

1. Click the Start Lab button. If you need to pay for the lab, a pop-up opens for you to select your payment method. On the left is the Lab Details panel with the following:

   • The Open Google Cloud console button

   • Time remaining

   • The temporary credentials that you must use for this lab

   • Other information, if needed, to step through this lab

2. Click Open Google Cloud console (or right-click and select Open Link in Incognito Window if you are running the Chrome browser).

   The lab spins up resources, and then opens another tab that shows the Sign in page.

   Tip: Arrange the tabs in separate windows, side-by-side.

   Note: If you see the Choose an account dialog, click Use Another Account.

3. If necessary, copy the Username below and paste it into the Sign in dialog.

    student-02-c9395d1a0b78@qwiklabs.net


   You can also find the Username in the Lab Details panel.

4. Click Next.

5. Copy the Password below and paste it into the Welcome dialog.

    42BMhGEk41xW


   You can also find the Password in the Lab Details panel.

6. Click Next.

   Important: You must use the credentials the lab provides you. Do not use your Google Cloud account credentials.

   Note: Using your own Google Cloud account for this lab may incur extra charges.

7. Click through the subsequent pages:

   • Accept the terms and conditions.

   • Do not add recovery options or two-factor authentication (because this is a temporary account).

   • Do not sign up for free trials.

After a few moments, the Google Cloud console opens in this tab.

Note: To view a menu with a list of Google Cloud products and services, click the Navigation menu at the top-left.

Activate Cloud Shell

Cloud Shell is a virtual machine that is loaded with development tools. It offers a persistent 5GB home directory and runs on the Google Cloud. Cloud Shell provides command-line access to your Google Cloud resources.

1. Click Activate Cloud Shell



   at the top of the Google Cloud console.

When you are connected, you are already authenticated, and the project is set to your Project_ID, qwiklabs-gcp-00-43066a0fc67c. The output contains a line that declares the Project_ID for this session:

Your Cloud Platform project in this session is set to qwiklabs-gcp-00-43066a0fc67c

gcloud is the command-line tool for Google Cloud. It comes pre-installed on Cloud Shell and supports tab-completion.

2. (Optional) You can list the active account name with this command:

gcloud auth list

3. Click Authorize.

Output:

ACTIVE: *
ACCOUNT: student-02-c9395d1a0b78@qwiklabs.net

To set the active account, run:
    $ gcloud config set account `ACCOUNT`

4. (Optional) You can list the project ID with this command:

gcloud config list project

Output:

[core]
project = qwiklabs-gcp-00-43066a0fc67c

Note: For full documentation of gcloud, in Google Cloud, refer to the gcloud CLI overview guide.

Task 1. Create a database for replication

In this section you will prepare a Cloud SQL for PostgreSQL database for Datastream replication.

Create the Cloud SQL database

1. Run the following command to enable the Cloud SQL API:

gcloud services enable sqladmin.googleapis.com

2. Run the following command to create a Cloud SQL for PostgreSQL database instance:

POSTGRES_INSTANCE=postgres-db
DATASTREAM_IPS=35.245.110.238,34.85.182.28,34.150.213.121,34.150.171.115,34.145.160.237
gcloud sql instances create ${POSTGRES_INSTANCE} \
    --database-version=POSTGRES_14 \
    --cpu=2 --memory=10GB \
    --authorized-networks=${DATASTREAM_IPS} \
    --region=us-east4 \
    --root-password pwd \
    --database-flags=cloudsql.logical_decoding=on

Note:This command creates the database inus-east4. For other regions, be sure to replace theDATASTREAM_IPSwith the rightDatastream Public IPsfor your region.

Once the database instance is created, make a note of the instance's public IP - you'll need this later when creating Datastream's connection profile.

Click Check my progress to verify the objective.

Create a database for replication

Check my progress

Populate the database with sample data

Connect to the PostgreSQL database by running the following command in Cloud Shell.

gcloud sql connect postgres-db --user=postgres

When prompted for the password, enter pwd.

Once connected to the database, run the following SQL command to create a sample schema and table:

CREATE SCHEMA IF NOT EXISTS test;

CREATE TABLE IF NOT EXISTS test.example_table (
id  SERIAL PRIMARY KEY,
text_col VARCHAR(50),
int_col INT,
date_col TIMESTAMP
);

ALTER TABLE test.example_table REPLICA IDENTITY DEFAULT;

INSERT INTO test.example_table (text_col, int_col, date_col) VALUES
('hello', 0, '2020-01-01 00:00:00'),
('goodbye', 1, NULL),
('name', -987, NOW()),
('other', 2786, '2021-01-01 00:00:00');

Configure the database for replication

• Run the following SQL command to create a publication and a replication slot:

CREATE PUBLICATION test_publication FOR ALL TABLES;
ALTER USER POSTGRES WITH REPLICATION;
SELECT PG_CREATE_LOGICAL_REPLICATION_SLOT('test_replication', 'pgoutput');

Task 2. Create the Datastream resources and start replication

Now that the database is ready, create the Datastream connection profiles and stream to begin replication.

1. From the Navigation menu, click on View All Products under Analytics select Datastream

2. Click Enable to enable the Datastream API.

Create connection profiles

Create two connection profiles, one for the PostgreSQL source, and another for the BigQuery destination.

PostgreSQL connection profile

1. In the Cloud console, navigate to the Connection Profiles tab and click Create Profile.

2. Select the PostgreSQL connection profile type.

3. Use postgres-cp as the name and ID of the connection profile.

4. Enter the database connection details:

• Region: us-east4

• The IP and port of the Cloud SQL instance created earlier

• Username: postgres

• Password: pwd

• Database: postgres

5. Click Continue.

6. Leave the encryption as NONE, and click CONTINUE.

7. Select the IP allowlisting connectivity method, and click Continue.

8. Click RUN TEST to make sure that Datastream can reach the database.

9. Click Create.

BigQuery connection profile

1. In the Cloud console, navigate to the Connection Profiles tab and click Create Profile.

2. Select the BigQuery connection profile type.

3. Use bigquery-cp as the name and ID of the connection profile.

4. Region us-east4

5. Click Create.

Create stream

Create the stream which connects the connection profiles created above and defines the configuration for the data to stream from source to destination.

• In the Cloud console, navigate to the Streams tab and click Create Stream.

Define the stream details

1. Use test-stream as the name and ID of the stream.

2. Region us-east4

3. Select PostgreSQL as the source type

4. Select BigQuery as destination type

5. Click CONTINUE.

Define the source

1. Select the postgres-cp connection profile created in the previous step.

2. [Optional] Test connectivity by clicking RUN TEST

3. Click CONTINUE.

Configure the source

1. Specify the replication slot name as test_replication.

2. Specify the publication name as test_publication.

3. Select the test schema for replication.

4. Click Continue.

Define the destination

• Select the bigquery-cp connection profile created in the previous step, then click Continue.

Configure the destination

1. Choose Region and select us-east4 as the BigQuery dataset location.

2. Set the staleness limit to 0 seconds.

3. Click Continue.

Review and create the stream

• Finally, validate the stream details by clicking RUN VALIDATION. Once validation completes successfully, click CREATE AND START.

Wait approximately 1-2 minutes until the stream status is shown as running.

Click Check my progress to verify the objective.

Create the Datastream resources

Check my progress

Task 3. View the data in BigQuery

Now that the stream is running, see the data replicating into the BigQuery dataset.

1. In the Google Cloud console, from the Navigation menu go to BigQuery.

2. In the BigQuery Studio explorer, expand the project node to see the list of datasets.

3. Expand the test dataset node.

4. Click on the example_table table.

5. Click on the PREVIEW tab to see the data in BigQuery.

Note: The data might take few minutes to appear in Preview section.

Task 4. Check that changes in the source are replicated to BigQuery

1. Run the following command in Cloud Shell to connect to the Cloud SQL database (the password is pwd):

gcloud sql connect postgres-db --user=postgres

2. Run the following SQL commands to make some changes to the data:

INSERT INTO test.example_table (text_col, int_col, date_col) VALUES
('abc', 0, '2022-10-01 00:00:00'),
('def', 1, NULL),
('ghi', -987, NOW());

UPDATE test.example_table SET int_col=int_col*2;

DELETE FROM test.example_table WHERE text_col = 'abc';

3. Open the BigQuery SQL workspace and run the following query to see the changes in BigQuery:

SELECT * FROM test.example_table ORDER BY id;

---

Solution of Lab

export DATASTREAM_IPS=

curl -LO raw.githubusercontent.com/QUICK-GCP-LAB/2-Minutes-Labs-Solutions/refs/heads/main/Datastream%20PostgreSQL%20Replication%20to%20BigQuery/gsp1052-1.sh
sudo chmod +x gsp1052-1.sh
./gsp1052-1.sh

• When prompted for the password, paste the following.

pwd

CREATE SCHEMA IF NOT EXISTS test;

CREATE TABLE IF NOT EXISTS test.example_table (
id  SERIAL PRIMARY KEY,
text_col VARCHAR(50),
int_col INT,
date_col TIMESTAMP
);

ALTER TABLE test.example_table REPLICA IDENTITY DEFAULT;

INSERT INTO test.example_table (text_col, int_col, date_col) VALUES
('hello', 0, '2020-01-01 00:00:00'),
('goodbye', 1, NULL),
('name', -987, NOW()),
('other', 2786, '2021-01-01 00:00:00');

CREATE PUBLICATION test_publication FOR ALL TABLES;
ALTER USER POSTGRES WITH REPLICATION;
SELECT PG_CREATE_LOGICAL_REPLICATION_SLOT('test_replication', 'pgoutput');

exit

curl -LO raw.githubusercontent.com/QUICK-GCP-LAB/2-Minutes-Labs-Solutions/refs/heads/main/Datastream%20PostgreSQL%20Replication%20to%20BigQuery/gsp1052-2.sh
sudo chmod +x gsp1052-2.sh
./gsp1052-2.sh

•

  Use postgres-cp as the name and ID of the connection profile.

• Use bigquery-cp as the name and ID of the connection profile.

• Use test-stream as the name and ID of the stream

• Specify the replication slot name as test_replication

• Specify the publication name as test_publication
