Extract, Analyze, and Translate Text from Images with the Cloud ML APIs - GSP075

Extract, Analyze, and Translate Text from Images with the Cloud ML APIs - GSP075

Overview

In this lab you'll explore the power of machine learning by using multiple machine learning APIs together. Start with Cloud Vision API's text detection method to make use of Optical Character Recognition (OCR) to extract text from images. Then, learn how to translate that text with the Translation API and analyze it with the Natural Language API.

Objectives

In this lab, you will:

  • Create a Vision API request and calling the API with curl

  • Use the text detection (OCR) method of the Vision API

  • Use the Translation API to translate text from your image

  • Use the Natural Language API to analyze the text

Setup and requirements

Before you click the Start Lab button

Read these instructions. Labs are timed and you cannot pause them. The timer, which starts when you click Start Lab, shows how long Google Cloud resources will be made available to you.

This hands-on lab lets you do the lab activities yourself in a real cloud environment, not in a simulation or demo environment. It does so by giving you new, temporary credentials that you use to sign in and access Google Cloud for the duration of the lab.

To complete this lab, you need:

  • Access to a standard internet browser (Chrome browser recommended).

Note: Use an Incognito or private browser window to run this lab. This prevents any conflicts between your personal account and the Student account, which may cause extra charges incurred to your personal account.

  • Time to complete the lab---remember, once you start, you cannot pause a lab.

Note: If you already have your own personal Google Cloud account or project, do not use it for this lab to avoid extra charges to your account.

How to start your lab and sign in to the Google Cloud console

  1. Click the Start Lab button. If you need to pay for the lab, a pop-up opens for you to select your payment method. On the left is the Lab Details panel with the following:

    • The Open Google Cloud console button

    • Time remaining

    • The temporary credentials that you must use for this lab

    • Other information, if needed, to step through this lab

  2. Click Open Google Cloud console (or right-click and select Open Link in Incognito Window if you are running the Chrome browser).

    The lab spins up resources, and then opens another tab that shows the Sign in page.

    Tip: Arrange the tabs in separate windows, side-by-side.

    Note: If you see the Choose an account dialog, click Use Another Account.

  3. If necessary, copy the Username below and paste it into the Sign in dialog.

     student-04-4f4758a1370b@qwiklabs.net


    You can also find the Username in the Lab Details panel.

  4. Click Next.

  5. Copy the Password below and paste it into the Welcome dialog.

     HCO7x7YvioD7


    You can also find the Password in the Lab Details panel.

  6. Click Next.

    Important: You must use the credentials the lab provides you. Do not use your Google Cloud account credentials.

    Note: Using your own Google Cloud account for this lab may incur extra charges.

  7. Click through the subsequent pages:

    • Accept the terms and conditions.

    • Do not add recovery options or two-factor authentication (because this is a temporary account).

    • Do not sign up for free trials.

After a few moments, the Google Cloud console opens in this tab.

Note: To view a menu with a list of Google Cloud products and services, click the Navigation menu at the top-left.

Navigation menu icon

Activate Cloud Shell

Cloud Shell is a virtual machine that is loaded with development tools. It offers a persistent 5GB home directory and runs on the Google Cloud. Cloud Shell provides command-line access to your Google Cloud resources.

  1. Click Activate Cloud Shell

    Activate Cloud Shell icon

    at the top of the Google Cloud console.

When you are connected, you are already authenticated, and the project is set to your Project_ID, qwiklabs-gcp-03-c7427acb43d2. The output contains a line that declares the Project_ID for this session:

Your Cloud Platform project in this session is set to qwiklabs-gcp-03-c7427acb43d2

gcloud is the command-line tool for Google Cloud. It comes pre-installed on Cloud Shell and supports tab-completion.

  1. (Optional) You can list the active account name with this command:
gcloud auth list
  1. Click Authorize.

Output:

ACTIVE: *
ACCOUNT: student-04-4f4758a1370b@qwiklabs.net

To set the active account, run:
    $ gcloud config set account `ACCOUNT`
  1. (Optional) You can list the project ID with this command:
gcloud config list project

Output:

[core]
project = qwiklabs-gcp-03-c7427acb43d2

Note: For full documentation of gcloud, in Google Cloud, refer to the gcloud CLI overview guide.

Task 1. Create an API key

Since you'll be using curl to send a request to the Vision API, generate an API key to pass in your request URL.

  1. To create an API key, navigate to: Navigation Menu > APIs & services > Credentials.

  2. Click + Create Credentials.

  3. In the drop down menu, select API key.

  4. Next, copy the key you just generated and click Close.

  5. Now save the API key to an environment variable to avoid having to insert the value of your API key in each request.

  6. Run the following in Cloud Shell, replacing <your_api_key> with the key you just copied:

export API_KEY=<YOUR_API_KEY>

Click Check my progress to verify your performed task.

Create an API Key

Check my progress

Task 2. Upload an image to a Cloud Storage bucket

Create a Cloud Storage bucket

There are two ways to send an image to the Vision API for image detection: by sending the API a base64 encoded image string, or passing it the URL of a file stored in Cloud Storage. For this lab you'll create a Cloud Storage bucket to store your images.

  1. Navigate to the Navigation menu > Cloud Storage browser in the Console, then click Create bucket.

  2. Give your bucket a unique name:qwiklabs-gcp-03-c7427acb43d2-bucket.

  3. After naming your bucket, click Choose how to control access to objects.

  4. Uncheck the box for Enforce public access prevention on this bucket.

  5. Choose Fine-grained under Access Control and click Create.

Upload an image to your bucket

  1. Right click on the following image of a French sign, then click Save image as and save it to your computer as sign.jpg.

Le Bien Public French sign

  1. Navigate to the bucket you just created in the Cloud Storage browser and click Upload > Upload files, then select sign.jpg.

Next you'll allow the file to be viewed publicly while keeping the access to the bucket private.

  1. Click on the 3 dots for the image file:

Objects tab with uploaded sign image file, and more options button highlighted

  1. Select Edit access.

  2. Click Add Entry and set the following:

  • Select Public for the Entity.

  • Ensure allUsers is the value for the Name.

  • Select Reader for the Access.

Entity, Name and Access fields of newly added entry highlighted

  1. Click Save.

You'll now see that the file has public access.

Now that you have the file in your bucket, you're ready to create a Vision API request, passing it the URL of this picture.

Click Check my progress to verify your performed task.

Upload image to a bucket

Check my progress

Task 3. Create your Cloud Vision API request

  1. In your Cloud Shell environment, create an ocr-request.json file, then add the code below to the file, replacing my-bucket-name with the name of the bucket you created. You can create the file using one of your preferred command line editors (nano, vim, emacs) or click the pencil icon to open the code editor in Cloud Shell:

Open Editor button displaying the pencil icon

  1. Add the following to your ocr-request.json file:
{
  "requests": [
      {
        "image": {
          "source": {
              "gcsImageUri": "gs://my-bucket-name/sign.jpg"
          }
        },
        "features": [
          {
            "type": "TEXT_DETECTION",
            "maxResults": 10
          }
        ]
      }
  ]
}

You're going to use the TEXT_DETECTION feature of the Cloud Vision API. This will run optical character recognition (OCR) on the image to extract text.

Task 4. Call the text detection method

  1. In Cloud Shell, call the Cloud Vision API with curl:
curl -s -X POST -H "Content-Type: application/json" --data-binary @ocr-request.json  https://vision.googleapis.com/v1/images:annotate?key=${API_KEY}

The first part of your response should look like the following:

{
  "responses": [
    {
      "textAnnotations": [
        {
          "locale": "fr",
          "description": "LE BIEN PUBLIC\nles dépêches\nPour Obama,\nla moutarde\nest\nde Dijon\n",
          "boundingPoly": {
            "vertices": [
              {
                "x": 138,
                "y": 40
              },
              {
                "x": 622,
                "y": 40
              },
              {
                "x": 622,
                "y": 795
              },
              {
                "x": 138,
                "y": 795
              }
            ]
          }
        },
        {
          "description": "LE",
          "boundingPoly": {
            "vertices": [
              {
                "x": 138,
                "y": 99
              },
              {
                "x": 274,
                "y": 82
              },
              {
                "x": 283,
                "y": 157
              },
              {
                "x": 147,
                "y": 173
              }
            ]
          }
        },
        {
          "description": "BIEN",
          "boundingPoly": {
            "vertices": [
              {
                "x": 291,
                "y": 79
              },
              {
                "x": 413,
                "y": 64
              },
              {
                "x": 422,
                "y": 139
              },
              {
                "x": 300,
                "y": 154
              }
            ]
          }
            ...
      ]
}]
}

The OCR method is able to extract lots of text from the image.

The first piece of data you get back from textAnnotations is the entire block of text the API found in the image. This includes:

  • the language code (in this case fr for French)

  • a string of the text

  • a bounding box indicating where the text was found in the image

Then you get an object for each word found in the text with a bounding box for that specific word.

Note: For images with more text, the Cloud Vision API also has a DOCUMENT_TEXT_DETECTION feature. This response includes additional information and breaks text down into page, blocks, paragraphs, and words.

Unless you speak French you probably don't know what this says. The next step is translation.

  1. Run the following curl command to save the response to an ocr-response.json file so it can be referenced later:
curl -s -X POST -H "Content-Type: application/json" --data-binary @ocr-request.json  https://vision.googleapis.com/v1/images:annotate?key=${API_KEY} -o ocr-response.json

Task 5. Send text from the image to the Translation API

The Translation API can translate text into 100+ languages. It can also detect the language of the input text. To translate the French text into English, pass the text and the language code for the target language (en-US) to the Translation API.

  1. First, create a translation-request.json file and add the following to it:
{
  "q": "your_text_here",
  "target": "en"
}

q is where you'll pass the string to translate.

  1. Save the file.

  2. Run this Bash command in Cloud Shell to extract the image text from the previous step and copy it into a new translation-request.json (all in one command):

STR=$(jq .responses[0].textAnnotations[0].description ocr-response.json) && STR="${STR//\"}" && sed -i "s|your_text_here|$STR|g" translation-request.json
  1. Now you're ready to call the Translation API. This command will also copy the response into a translation-response.json file:
curl -s -X POST -H "Content-Type: application/json" --data-binary @translation-request.json https://translation.googleapis.com/language/translate/v2?key=${API_KEY} -o translation-response.json
  1. Run this command to inspect the file with the Translation API response:
cat translation-response.json

Now you can understand more of what the sign said!

{
  "data": {
    "translations": [
      {
        "translatedText": "TO THE PUBLIC GOOD the dispatches For Obama, the mustard is from Dijon",
        "detectedSourceLanguage": "fr"
      }
    ]
  }
}

In the response:

  • translatedText contains the resulting translation

  • detectedSourceLanguage is fr, the ISO language code for French.

The Translation API supports 100+ languages, all of which are listed in the Language support reference.

In addition to translating the text from our image, you might want to do more analysis on it. That's where the Natural Language API comes in handy. Onward to the next step!

Task 6. Analyzing the image's text with the Natural Language API

The Natural Language API helps you understand text by extracting entities, analyzing sentiment and syntax, and classifying text into categories. Use the analyzeEntities method to see what entities the Natural Language API can find in the text from your image.

  1. To set up the API request, create a nl-request.json file with the following:
{
  "document":{
    "type":"PLAIN_TEXT",
    "content":"your_text_here"
  },
  "encodingType":"UTF8"
}

In the request, you're telling the Natural Language API about the text you're sending:

  • type: supported type values are PLAIN_TEXT or HTML.

  • content: pass the text to send to the Natural Language API for analysis. The Natural Language API also supports sending files stored in Cloud Storage for text processing. To send a file from Cloud Storage, replace content with gcsContentUri and use the value of the text file's uri in Cloud Storage.

  • encodingType: tells the API which type of text encoding to use when processing the text. The API will use this to calculate where specific entities appear in the text.

  1. Run this Bash command in Cloud Shell to copy the translated text into the content block of the Natural Language API request:
STR=$(jq .data.translations[0].translatedText  translation-response.json) && STR="${STR//\"}" && sed -i "s|your_text_here|$STR|g" nl-request.json

The nl-request.json file now contains the translated English text from the original image. Time to analyze it!

  1. Call the analyzeEntities endpoint of the Natural Language API with this curl request:
curl "https://language.googleapis.com/v1/documents:analyzeEntities?key=${API_KEY}" \
  -s -X POST -H "Content-Type: application/json" --data-binary @nl-request.json

If you scroll through the response you can see the entities the Natural Language API found:

{
  "entities": [
    {
      "name": "dispatches",
      "type": "OTHER",
      "metadata": {},
      "salience": 0.3560996,
      "mentions": [
        {
          "text": {
            "content": "dispatches",
            "beginOffset": 23
          },
          "type": "COMMON"
        }
      ]
    },
    {
      "name": "mustard",
      "type": "OTHER",
      "metadata": {},
      "salience": 0.2878307,
      "mentions": [
        {
          "text": {
            "content": "mustard",
            "beginOffset": 38
          },
          "type": "COMMON"
        }
      ]
    },
    {
      "name": "Obama",
      "type": "PERSON",
      "metadata": {
        "mid": "/m/02mjmr",
        "wikipedia_url": "https://en.wikipedia.org/wiki/Barack_Obama"
      },
      "salience": 0.16260329,
      "mentions": [
        {
          "text": {
            "content": "Obama",
            "beginOffset": 31
          },
          "type": "PROPER"
        }
      ]
    },
    {
      "name": "Dijon",
      "type": "LOCATION",
      "metadata": {
        "mid": "/m/0pbhz",
        "wikipedia_url": "https://en.wikipedia.org/wiki/Dijon"
      },
      "salience": 0.08129317,
      "mentions": [
        {
          "text": {
            "content": "Dijon",
            "beginOffset": 54
          },
          "type": "PROPER"
        }
      ]
    }
  ],
  "language": "en"
}

For entities that have a wikipedia page, the API provides metadata including the URL of that page along with the entity's mid. The mid is an ID that maps to this entity in Google's Knowledge Graph. To get more information on it, you could call the Knowledge Graph API, passing it this ID. For all entities, the Natural Language API tells us the places it appeared in the text (mentions), the type of entity, and salience (a [0,1] range indicating how important the entity is to the text as a whole). In addition to English, the Natural Language API also supports the languages listed in the Language Support reference.

Looking at this image it's relatively easy to pick out the important entities, but if you had a library of thousands of images this would be much more difficult. OCR, translation, and natural language processing can help to extract meaning from large datasets of images.


Solution of Lab

export API_KEY=

curl -LO raw.githubusercontent.com/quiccklabs/Labs_solutions/master/Detect%20Labels%20Faces%20and%20Landmarks%20in%20Images%20with%20the%20Cloud%20Vision%20API/quicklabgsp037.sh
sudo chmod +x quicklabgsp037.sh
./quicklabgsp037.sh
