Perform Predictive Data Analysis in BigQuery: Challenge Lab - GSP374

Overview

In a challenge lab you’re given a scenario and a set of tasks. Instead of following step-by-step instructions, you will use the skills learned from the labs in the course to figure out how to complete the tasks on your own! An automated scoring system (shown on this page) will provide feedback on whether you have completed your tasks correctly.

When you take a challenge lab, you will not be taught new Google Cloud concepts. You are expected to extend your learned skills, like changing default values and reading and researching error messages to fix your own mistakes.

To score 100% you must successfully complete all tasks within the time period!

This lab is recommended for students who have enrolled in the Perform Predictive Data Analysis in BigQuery skill badge. Are you ready for the challenge?

Topics tested:

• Upload files from Cloud Storage into BigQuery tables using the console

• Write and execute queries that join information from multiple tables

• Analyze soccer event data using various BigQuery features

• Write functions in BigQuery to help with calculations to be performed on soccer shot data

• Create and evaluate an expected goals model using BigQuery ML

• Apply an expected goals model to make a prediction from new data using BigQuery ML

Setup and requirements

Before you click the Start Lab button

Read these instructions. Labs are timed and you cannot pause them. The timer, which starts when you click Start Lab, shows how long Google Cloud resources will be made available to you.

This hands-on lab lets you do the lab activities yourself in a real cloud environment, not in a simulation or demo environment. It does so by giving you new, temporary credentials that you use to sign in and access Google Cloud for the duration of the lab.

To complete this lab, you need:

• Access to a standard internet browser (Chrome browser recommended).

Note: Use an Incognito or private browser window to run this lab. This prevents any conflicts between your personal account and the Student account, which may cause extra charges incurred to your personal account.

• Time to complete the lab---remember, once you start, you cannot pause a lab.

Note: If you already have your own personal Google Cloud account or project, do not use it for this lab to avoid extra charges to your account.

How to start your lab and sign in to the Google Cloud console

1. Click the Start Lab button. If you need to pay for the lab, a pop-up opens for you to select your payment method. On the left is the Lab Details panel with the following:

   • The Open Google Cloud console button

   • Time remaining

   • The temporary credentials that you must use for this lab

   • Other information, if needed, to step through this lab

2. Click Open Google Cloud console (or right-click and select Open Link in Incognito Window if you are running the Chrome browser).

   The lab spins up resources, and then opens another tab that shows the Sign in page.

   Tip: Arrange the tabs in separate windows, side-by-side.

   Note: If you see the Choose an account dialog, click Use Another Account.

3. If necessary, copy the Username below and paste it into the Sign in dialog.

    student-02-757f969aadcd@qwiklabs.net


   You can also find the Username in the Lab Details panel.

4. Click Next.

5. Copy the Password below and paste it into the Welcome dialog.

    c9nfoKuvG1Jm


   You can also find the Password in the Lab Details panel.

6. Click Next.

   Important: You must use the credentials the lab provides you. Do not use your Google Cloud account credentials.

   Note: Using your own Google Cloud account for this lab may incur extra charges.

7. Click through the subsequent pages:

   • Accept the terms and conditions.

   • Do not add recovery options or two-factor authentication (because this is a temporary account).

   • Do not sign up for free trials.

After a few moments, the Google Cloud console opens in this tab.

Note: To view a menu with a list of Google Cloud products and services, click the Navigation menu at the top-left.

Challenge scenario

Use BigQuery to load the data from the Cloud Storage bucket, write and execute queries in BigQuery, analyze soccer event data. Then use BigQuery ML to train an expected goals model on the soccer event data and evaluate the impressiveness of World Cup goals.

Task 1. Data ingestion

1. Load the tables created with JavaScript Object Notation (JSON) and CSV data format into the dataset using the following information:

2. Load another table of soccer data format CSV into the dataset using the following information below:

Click Check my progress to verify the objective

Check tables are created

Check my progress

Task 2. Analyze soccer data

• Build a query that shows the success rate on penalty kicks by each player.

Points to consider:

• Join the events545 table with the players table to get player names from their IDs

• Filter on penalty kicks

• Group by player ID and player name

• Player should attempt at least 5 penalty kicks

• Order by penalty kick success rate

Note: Tag 101 represents a goal using the tags3name table.

Click Check my progress to verify the objective:

Check penalty kick success rate

Check my progress

Task 3. Gain insight by analyzing soccer data

• Create a new query to analyze shot distance. For shots, use (x, y) values from the positions field in the events545 table.

Points to consider:

• Calculate shot distance using the midpoint of the goal mouth (90, 55) as the ending location.

• Calculate pass distance by x-coordinate and y-coordinate differences, then convert to estimated meters using the average dimensions of a soccer field (116 x 66).

• Add an isGoal field by looking "inside" the tags field.

• Filter the events545 table to shots only.

• Shot distance must be less than 50.

• The final SELECT statement aggregates the number of shots, the number of goals and the percentage of goals from shots by distance rounded to the nearest meter.

Note: The approximate dimensions of a soccer field are used with the x-coordinate and y-coordinate distances as inputs to the distance formula.

Click Check my progress to verify the objective:

Analyze shot distance

Check my progress

Task 4. Create a regression model using soccer data

Create some user-defined functions in BigQuery that help with shot distance and angle calculations, which help to prepare the soccer event data for eventual use in an ML model.

Calculate shot distance from (x,y) coordinates

• Define a function soccer.GetShotDistanceToGoal545 for calculating the shot distance from (x,y) coordinates in the soccer dataset using the following code-blocks:

CREATE FUNCTION `soccer.GetShotDistanceToGoal545`(x INT64, y INT64)
RETURNS FLOAT64
AS (
 /* Translate 0-100 (x,y) coordinate-based distances to absolute positions
 using "average" field dimensions of 116x66 before combining in 2D dist calc */
 SQRT(
   POW((90 - x) * 116/100, 2) +
   POW((55 - y) * 66/100, 2)
   )
 );

Click Check my progress to verify the objective

Calculate shot distance

Check my progress

Calculate shot angle from (x,y) coordinates

• Define a function soccer.GetShotAngleToGoal545 for calculating the shot angle from (x,y) coordinates in the soccer dataset using the following code-blocks:

CREATE FUNCTION `soccer.GetShotAngleToGoal545`(x INT64, y INT64)
RETURNS FLOAT64
AS (
 SAFE.ACOS(
   /* Have to translate 0-100 (x,y) coordinates to absolute positions using
   "average" field dimensions of 116x66 before using in various distance calcs */
   SAFE_DIVIDE(
     ( /* Squared distance between shot and 1 post, in meters */
       (POW(116 - (x * 116/100), 2) + POW(33 + (7.32/2) - (y * 66/100), 2)) +
       /* Squared distance between shot and other post, in meters */
       (POW(116 - (x * 116/100), 2) + POW(33 - (7.32/2) - (y * 66/100), 2)) -
       /* Squared length of goal opening, in meters */
       POW(7.32, 2)
     ),
     (2 *
       /* Distance between shot and 1 post, in meters */
       SQRT(POW(116 - (x * 116/100), 2) + POW(33 + 7.32/2 - (y * 66/100), 2)) *
       /* Distance between shot and other post, in meters */
       SQRT(POW(116 - (x * 116/100), 2) + POW(33 - 7.32/2 - (y * 66/100), 2))
     )
    )
  /* Translate radians to degrees */
  ) * 180 / ACOS(-1)
 )
;

Click Check my progress to verify the objective

Calculate shot angle

Check my progress

Create an expected goals model using BigQuery ML

1. Use BigQuery ML to create and execute a machine learning model soccer.xg_logistic_reg_model_545 in BigQuery using standard SQL queries.

In this case, you build an expected goals model from the soccer event data to predict the likelihood of a shot going in for a goal given its type, distance, and angle.

Expected goals models are commonly used in soccer analytics to measure the quality of shots and finishing/saving ability given shot quality, and they have a variety of applications in both retrospective match analysis and making projections.

Points to consider:

• The top section will be the actual model creation code, specify the type of model and label for the outcome variable.

• 101 is a known Tag for 'goals' from the goals table.

• The SELECT statement aggregates isGoal outcome variable along with features of interest from the event data, shot distance, and angle calculated using the user-defined functions defined in the previous step.

• Join enables the determination of which competition each shot came from.

• Filter out World Cup matches for model fitting purposes and include both "open play" & free kick shots (including penalties).

Click Check my progress to verify the objective

Create BigQuery logistic regression model

Check my progress

2. Once the model is done training - look for a "Query complete" notification in the Query results section - click Go to model at the far right next to the message about model creation.

This opens up a new tab that has information about the model that was just trained.

3. Click to EVALUATION tab and look at the metrics, particularly Log loss and ROC AUC under Aggregate Metrics.

Task 5. Make predictions from new data with the BigQuery model

Now that you've fit an expected goals model of reasonable accuracy and explainability, you can apply it to "new" data - in this case, the 2018 World Cup (which was left out of the model fitting).

The logistic regression model soccer.xg_logistic_reg_model_545 created in the previous step is used to assess the difficulty of each shot and goal in that competition, enabling the identification of the most "impressive" goals in the tournament.

Get probabilities for all shots in the 2018 World Cup

• Use BigQuery ML's prediction functionality with the logistic regression model fit in the previous step to look at the probability of each shot scoring in the World Cup.

Points to consider:

• The top section is the actual model prediction code, specifying the type of model.

• The SELECT statement aggregates isGoal outcome variable along with features of interest from the event data, shot distance, and angle calculated using the user-defined functions defined in the previous step.

• Join enables the determination of which competition each shot came from.

• Look only at World Cup matches for model predictions and include both "open play" and free kick shots (including penalties).

Click Check my progress to verify the objective

Make predictions from the model

---

Solution of Lab

export EVENT_NAME=
export TABLE_NAME=
export VALUE_X_1=
export VALUE_Y_1=
export VALUE_X_2=
export VALUE_Y_2=
export FUNCTION_1=
export FUNCTION_2=
export MODEL_NAME=

curl -LO raw.githubusercontent.com/quiccklabs/Labs_solutions/master/Predict%20Soccer%20Match%20Outcomes%20with%20BigQuery%20ML%20Challenge%20Lab/quicklabgsp374.sh
sudo chmod +x quicklabgsp374.sh
./quicklabgsp374.sh

Task 4:

Open https://console.cloud.google.com/bigquery

Calculate shot distance from (x,y) coordinates

Calculate shot angle from (x,y) coordinates
