Overview

• Labs are timed and cannot be paused. The timer starts when you click Start Lab.

• The included cloud terminal is preconfigured with the gcloud SDK.

• Use the terminal to execute commands and then click Check my progress to verify your work.

Challenge scenario

You're the cloud architect for a cybersecurity firm. One of your client's virtual machines (VM) in a Google Cloud VPC network (client-vpc) has been compromised by a sophisticated attacker. The attacker is attempting to pivot laterally to other VMs within the network. Your task is to:

1. Isolate the compromised VM: Immediately isolate the VM (compromised-vm) from the rest of the client-vpc network by denying the traffic to prevent further lateral movement by removing all ingress access in the existing firewall rule called critical-fw-rule.

Click Check my progress to verify the objective.

Update the firewall rule.

1. Maintain Limited Access: Allow SSH access to the compromised-vm from a specific bastion host (bastion-host) so that your incident response team can investigate the attack. Create this as a new firewall rule called allow-ssh-from-bastion.

Click Check my progress to verify the objective.

Create the firewall rule.

1. Log and Monitor: Enable VPC flow logs for the subnet my-subnet to capture all network traffic to and from the isolated VM for further analysis.

Click Check my progress to verify the objective.

Enable VPC flow logs for the subnet.

---

Solution of Lab

curl -LO raw.githubusercontent.com/ePlus-DEV/storage/refs/heads/main/labs/respond-to-a-security-incident-solution/lab.sh
source lab.sh

Script Alternative

gcloud compute firewall-rules delete critical-fw-rule --quiet 2>/dev/null; gcloud compute firewall-rules create critical-fw-rule --network=client-vpc --direction=INGRESS --priority=1000 --action=DENY --rules=tcp:80,tcp:22 --target-tags=compromised-vm --enable-logging
gcloud compute firewall-rules delete allow-ssh-from-bastion --quiet 2>/dev/null; gcloud compute firewall-rules create allow-ssh-from-bastion --network=client-vpc --action allow --direction=ingress --rules tcp:22 --source-ranges=\((gcloud compute instances describe bastion-host --zone=\)(gcloud compute instances list --filter="name=bastion-host" --format="get(zone)") --format="get(networkInterfaces[0].accessConfigs[0].natIP)") --target-tags=compromised-vm
gcloud compute networks subnets update my-subnet --region=$(gcloud compute networks subnets list --filter="name=my-subnet" --format="get(region)") --enable-flow-logs
