Creating a Containerized Application with Buildpacks

Creating a Containerized Application with Buildpacks

David Nguyen's photo
David Nguyen
·

7 min read

Table of contents

Overview

Buildpacks are another approach for building container images and provide an alternate approach to turn your source code into a container image. Buildpacks are distributed and executed in images called builders. Each builder can have one or more buildpacks. A builder turns your source code into a container image. The buildpacks do the actual work to build and package the container image that you can deploy to Cloud Run or run with Docker locally.

You can create your own buildpacks, or use those provided by multiple vendors. Google Cloud's buildpacks allow developers to create and deploy containerized applications without the need to install Docker locally, or create a Dockerfile. Buildpacks are also built into Cloud Run to enable a source-based deployment workflow.

Objectives

In this lab, you:

  • Build an application with pack, a command-line tool that is used with builders to create container images from source code.

  • Use the Google Cloud's buildpacks builder to build a container image.

  • Run and test the container locally with Docker.

  • Build and redeploy the container to Cloud Run.

Setup

For each lab, you get a new Google Cloud project and set of resources for a fixed time at no cost.

  1. Sign in to Qwiklabs using an incognito window.

  2. Note the lab's access time (for example, 1:15:00), and make sure you can finish within that time.
    There is no pause feature. You can restart if needed, but you have to start at the beginning.

  3. When ready, click Start lab.

  4. Note your lab credentials (Username and Password). You will use them to sign in to the Google Cloud Console.

  5. Click Open Google Console.

  6. Click Use another account and copy/paste credentials for this lab into the prompts.
    If you use other credentials, you'll receive errors or incur charges.

  7. Accept the terms and skip the recovery resource page.

Activate Google Cloud Shell

Google Cloud Shell is a virtual machine that is loaded with development tools. It offers a persistent 5GB home directory and runs on the Google Cloud.

Google Cloud Shell provides command-line access to your Google Cloud resources.

  1. In Cloud console, on the top right toolbar, click the Open Cloud Shell button.

    Highlighted Cloud Shell icon

  2. Click Continue.

It takes a few moments to provision and connect to the environment. When you are connected, you are already authenticated, and the project is set to your PROJECT_ID. For example:

Project ID highlighted in the Cloud Shell Terminal

gcloud is the command-line tool for Google Cloud. It comes pre-installed on Cloud Shell and supports tab-completion.

  • You can list the active account name with this command:
gcloud auth list

Output:

Credentialed accounts:
 - @.com (active)

Example output:

Credentialed accounts:
 - google1623327_student@qwiklabs.net
  • You can list the project ID with this command:
gcloud config list project

Output:

[core]
project =

Example output:

[core]
project = qwiklabs-gcp-44776a13dea667a6

Note: Full documentation of gcloud is available in the gcloud CLI overview guide .

Task 1. Configure your environment and project

In this task, you set environment variables, and configure your Cloud Shell environment.

Configure your Cloud Shell environment

  1. To set your project ID and region environment variables, in Cloud Shell, run the following commands:

     PROJECT_ID=$(gcloud config get-value project)
 REGION=us-central1

  2. Set the compute region in Cloud Shell:

     gcloud config set compute/region $REGION

Enable Google APIs

  • To use Cloud Run, and the Google Translate API later in this lab, enable relevant APIs for your project:

      gcloud services enable artifactregistry.googleapis.com run.googleapis.com translate.googleapis.com

Click Check my progress to verify the objective.

Enabled Google APIs

Check my progress

Task 2. Build and run an application with Docker

In this task, you build a sample application with the pack command line tool and the Google Cloud's buildpacks builder.

Develop the application

  1. Create an app directory and change to it:

     mkdir app && cd app

  2. Copy the sample python application for this lab from Cloud Storage, and extract the contents from the archive:

     gsutil cp gs://cloud-training/CBL513/sample-apps/sample-py-app.zip . && unzip sample-py-app

  3. View the sample application files and source code:

     ls sample-py-app

     cat sample-py-app/main.py

    Because the Python buildpack does not generate a default container entry-point for the application, we use a Procfile to configure the application's start command.

    The application is written in Python and returns a sample welcome message in response to a request made to the application.

Build the container

  1. Change to the sample application directory:

     cd sample-py-app

  2. To build the container, run pack:

     pack build --builder=gcr.io/buildpacks/builder sample-py-app

    A partial output is similar to:

     ...
 ...
 [exporter] Setting default process type 'web'
 [exporter] Saving sample-py-app...
 [exporter] *** Images (9f9f9a48fd46):
 [exporter]       sample-py-app
 [exporter] Adding cache layer 'google.python.pip:pip'
 [exporter] Adding cache layer 'google.python.pip:pipcache'
 Successfully built image sample-py-app

    Note: With pack, you did not need to write and provide a Dockerfile to build the container image.

  3. To view the images downloaded and built in your Cloud Shell host, run:

     docker images

     REPOSITORY                  TAG       IMAGE ID       CREATED        SIZE
 gcr.io/buildpacks/builder   latest    514fb6f1bbfe   29 hours ago   804MB
 gcr.io/buildpacks/gcp/run   v1        22db1b5e48e3   29 hours ago   177MB
 buildpacksio/lifecycle      0.16.0    67e021546a3f   43 years ago   30.5MB
 sample-py-app               latest    9f9f9a48fd46   43 years ago   571MB

  4. Run the container locally in Docker by passing in the PORT environment variable to the application and binding the host's port 8080 to the container port:

     docker run -it -e PORT=8080 -p 8080:8080 -d sample-py-app

    The application code listens on the port that is provided in the environment variable, in this case, port 8080.

  5. Test the containerized application with the curl command:

     curl http://localhost:8080/

    You should see the following message as a response:

     Welcome to this sample app, built with Buildpacks.

Task 3. Build and run an application on Cloud Run

Typically, as a next step in your development and deployment lifecycle, you should push the container image that you built in the previous task to Artifact Registry, and then deploy the image to a container-based environment like Google Kubernetes Engine or Cloud Run.

In this task, you modify the sample application code, then build and deploy the containerized application directly from source with Cloud Run.

Modify the application code

You modify the sample application code to use the Google Translation API that translates a piece of text from English to Spanish.

  1. Edit the main.py file with an editor of your choice, for example, vi or nano. You can also click Open Editor from the Cloud Shell menu to edit the file.

  2. Replace the entire contents of the main.py file with the code below:

     from flask import Flask, request
 import google.auth
 from google.cloud import translate

 app = Flask(__name__)
 _, PROJECT_ID = google.auth.default()
 TRANSLATE = translate.TranslationServiceClient()
 PARENT = 'projects/{}'.format(PROJECT_ID)
 SOURCE, TARGET = ('en', 'English'), ('es', 'Spanish')

 @app.route('/', methods=['GET', 'POST'])
 def index():
     # reset all variables
     text = translated = None

     if request.method == 'POST':
         text = request.get_json().get('text').strip()
         if text:
             data = {
                 'contents': [text],
                 'parent': PARENT,
                 'target_language_code': TARGET[0],
             }
             # handle older call for backwards-compatibility
             try:
                 rsp = TRANSLATE.translate_text(request=data)
             except TypeError:
                 rsp = TRANSLATE.translate_text(**data)
             translated = rsp.translations[0].translated_text

     # create context
     context = {
         'trtext': translated
     }
     return context

 if __name__ == "__main__":
     # Dev only: run "python main.py" and open http://localhost:8080
     import os
     app.run(host="localhost", port=int(os.environ.get('PORT', 8080)), debug=True)

    The application code uses the Google Translate API to translate a piece of text passed in a JSON request from English to Spanish.

Build and deploy the container

  1. To build and deploy the container on Cloud Run, execute the following command:

     gcloud run deploy sample-py-app --source . --region=${REGION} --allow-unauthenticated

    The allow-unauthenticated option enables access to the service without requiring any authentication.

  2. When prompted, type Y to accept the default repository that is created in Artifact Registry to store the container image.

  3. When the command completes, a Cloud Run service named sample-py-app is created.

    The command output is similar to:

     Building using Buildpacks and deploying container to Cloud Run service [sample-py-app] in project [qwiklabs-gcp-00-0d56d42aca1a] region [asia-east1]
 OK Building and deploying new service... Done.
 OK Creating Container Repository...
 OK Uploading sources...
 OK Building Container... Logs are available at [https://console.cloud.google.com/cloud-build/builds/8bea2ded-4745-41f9-a82d-128e409daa20?project=34240880885].
 OK Creating Revision...
 OK Routing traffic...
 OK Setting IAM Policy...
 Done.
 Service [sample-py-app] revision [sample-py-app-00001-nec] has been deployed and is serving 100 percent of traffic.
 Service URL: https://sample-py-app-ulvp7xw3bq-de.a.run.app

Test the Cloud Run service

  1. Set an environment variable for the Cloud Run service that was created in the previous step:

     SERVICE_URL=[SERVICE URL]

    Replace the [SERVICE URL] with the value returned from Cloud Run in the output of the command in the previous step.

  2. To test the service, , and execute the curl command:

     curl $SERVICE_URL -H 'Content-Type: application/json' -d '{"text" : "Welcome to this sample app, built with Google Cloud buildpacks."}'

     {"trtext":"Bienvenido a esta aplicaci\u00f3n de muestra, creada con paquetes de compilaci\u00f3n de Google Cloud."}

Click Check my progress to verify the objective.

Solution of Lab

https://www.youtube.com/watch?v=mL8JQqb2fIk

export REGION=


curl -LO raw.githubusercontent.com/Techcps/GSP-Short-Trick/master/Creating%20a%20Containerized%20Application%20with%20Buildpacks/techcps.sh
sudo chmod +x techcps.sh
./techcps.sh
